Fractal Design Meshify 3 Black RGB Mid Tower PC Gaming Case

Images

Videos

Fractal Design Meshify 3 RGB, Black, Mid Tower w/ Light TG, 3x 140mm Fans, USB 3.2 Gen2, E-ATX / ATX / mATX/ mITX

Scan Code:LN153564

Manufacturer Code:FD-C-MES3A-06

Customer Reviews and Q&A

Meshify 3 RGB Black Mid Tower Chassis from Fractal Design

A classic, evolved. Meshify 3 is a performance PC case combining top-tier cooling with fluid, aerodynamic design. An evolution of Fractal's classic series, Meshify 3 includes several performance-boosting engineering upgrades and three powerful Momentum fans. The Ambience Pro RGB version enhances the experience further with ARGB Gen 2 integrated atmospheric lighting and fans, which are easily controlled through Fractal's intuitive web-based software accessed via the included Adjust Pro Hub.

Please note: Images are for illustrative purposes, you are viewing the Meshify 3 RGB Black version.

Evolved Design

See all of your system and components through the Light Tempered Glass window of the Meshify 3 RGB version.

Crafted by Fractal Design Elevate your space with an aerodynamic design aesthetic featuring a sleek, rockface-inspired mesh front panel.

A clean finish Achieve a neat and tidy look with a clean interior layout featuring a cable cover and new cable aligners for easy routing.

Designed for gaming Create a powerful gaming system with space for graphics cards up to 349 mm in length and E-ATX (277 mm) motherboard compatibility.

Easily Accessible

Build without a fuss Enjoy a smooth build experience with easily removable panels, including a sliding top panel featuring a fabric tab.

Radiator Compatibility

Quick cooler installation Cool your build further with up to a 280 mm top radiator and 360 mm front radiator, with removable brackets for easy installation.

Advanced Airflow

Cooler components Access performance engineering with ample ventilation and an air guide which directs airflow towards components to improve GPU cooling.

Powerful Fans Included

Fractal Momentum 14 fans Includes three high-performance Momentum 14 fans, featuring LCP blades and true FDB bearings for improved cooling and quieter operation.

Accessible I/O

Connections made easy Connect your devices easily with a top I/O featuring a 20 Gbps USB Type-C port, two USB-A ports and a combined audio jack.

Specifications

Core Chassis Specifications
Case Edition	Meshify 3 RGB Black
Case Form Factor	Mid Tower
Motherboard Form Factor	ATX E-ATX (277mm Wide Max.) MicroATX Mini-ITX
Back Connect Compatible	No

I/O, Bays & Expansion
Front/Side/Top Panel I/O	1 x Headphone/Mic Combo 1 x Power Button 2 x USB 3.2 Gen1 Type-A 1 x USB 3.2 Gen2x2 Type-C
Drive Bays	2 x 2.5" Internal 2 x 3.5" / 4x 2.5" Internal
Standard Expansion Slots	7
Vertical Expansion Slots

Fans & Filters
Fan Bays	6 x 120mm / 5x 140mm
Fans Included	3 x 140mm w/ Addressable RGB LEDs
Fan Controller/Hub
Dust Filters	Bottom

Liquid Cooling Support
Front Radiator Compatibility	1 x 280/360mm
Top Radiator Compatibility	1 x 240/280mm
Bottom Radiator Compatibility
Rear Radiator Compatibility	1 x 120mm
Side Radiator Compatibility

Clearances
Max CPU Cooler Height	173 mm
Max GPU Card Length	349 mm
Cable Routing Space	34.5 mm

Side Panels
Window/s	Yes
Window Configuration	1 x Main Side
Window Construction	Tempered Glass (Tinted)

LED Lighting Functionality
LED Lighting	Yes
LED Lighting Emitters	Included Addressable LED Fan/s
LED Lighting Colour	RGB
LED Lighting Support & Control

Power Supply Compatibility
PSU Included	No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support	ATX
PSU Mounting Location	Bottom Mount, Rear
Max PSU Length	180 mm

Chassis Physical Specifications
Colour	Black
Chassis Construction Materials	Steel / Tempered Glass
Dimensions	229 x 507 x 433 (WxHxD mm)
Weight	8.8 kg (Approx)
Package Type	Retail
Please Note

Additional Information
Scan Code	LN153564
Model Number	FD-C-MES3A-06
GTIN	7340172709503
