3XS - Corsair MP600 PRO NH 1TB, M.2 (2280) PCIe 4.0 (x4) NVMe SSD, 7000MB/s Read, 5700MB/s Write, 87

Images

3XS - Corsair MP600 PRO NH 1TB, M.2 (2280) PCIe 4.0 (x4) NVMe SSD, 7000MB/s Read, 5700MB/s Write, 870k/1100k

Scan Code:LN138244

Manufacturer Code:CSSD-F1000GBMP600PNH-3XS

Customer Reviews and Q&A

Product Overview

MP600 PRO NH

The CORSAIR MP600 PRO NH Gen4 PCIe x4 NVMe M.2 SSD uses Gen4 PCIe technology to achieve unbelievably fast sequential read speeds of up to 7,000MB/sec and sequential write speeds of up to 6,500MB/sec, without a pre-installed heatsink. High-density TLC NAND flash memory offers an ideal mix of performance and endurance, with longevity up to 6,000TB Written. Contained in a compact M.2 2280 form factor and connecting over a high-speed NVMe 1.4 PCIe Gen4 x4 M.2 interface, and is backed by a five-year warranty. If you’re looking for extreme storage performance, go with Gen4 for blazing fast speed.

Features

Specifications
Capacity	1TB
Edition	MP600 PRO NH
Form Factor	M.2 (2280)
Height	3 mm
Interface	PCIe 4.0 (x4)
Host Controller Interface	NVMe 1.4
Controller	Phison
Flash Memory Type	3D TLC
Max. Read	7000 MB/s
Max. Write	5700 MB/s
DRAM Cache Memory	N/A
DRAM Cache Memory Type
Max. Random Read 4K	870,000 IOPS
Max. Random Write 4K	1,100,000 IOPS
Latency	N/A
Special Features	AES 256-bit Encryption Support Corsair SSD Toolbox Software Support Garbage Collection S.M.A.R.T Support TRIM Support
Power Consumption (active)	8.8W (Read), 7.5W (Write)
Max. Endurance Rating	700TBW
MTBF	1,600,000 Hours
Max. Operating Vibration	20Hz~80Hz/1.52mm
Max. Non-operating Vibration
Max. Operating Shock	1500G
Max. Non-operating Shock
Connectivity	1 x M.2 (PCIe)
OS Support
Bracket	N/A
Dimensions	22 x 3 x 80 mm (WxHxD)
Weight	8.2 g
Package Type	OEM

Additional Information
Scan Code	LN138244
Model Number	CSSD-F1000GBMP600PNH-3XS
