Cooler Master MasterFrame 600 Silver ARGB Mid Tower PC Gaming Case

Images

Cooler Master MasterFrame 600, Silver, Mid Tower w/ TG Window, 4x SickleFlow ARGB Fans, mITX / mATX/ ATX / EATX

Scan Code:LN160552

Manufacturer Code:MF600-SGNN-S00

Customer Reviews and Q&A

MasterFrame 600 Silver ARGB Premium Modular ATX PC Case

Unique design from Cooler Master The MasterFrame 600 is a premium open-frame mid-tower chassis built for high-performance hardware, extreme cooling, and total customisation. Designed with FreeForm 2.0 in mind, it supports ATX to E-ATX motherboards and offers full access to modular design files, empowering users to build and evolve without limits. The Silver ARGB features 4x SickleFlow ARGB Fans.

Please note: Images are for illustration purposes, you are viewing the Cooler Master MasterFrame 600 Silver ARGB version.

Stylish Swappable Panel

Tool-free panel removal Easily remove side panels and other components without tools for quick access and modifications during build or upgrades. The MasterFrame 600 offers stylish customisation options with a swappable panel.
*Availability may differ based on region.

Flexible Build Options

MasterFrame 600 Silver ARGB • Rear Sickleflow 120 ARGB PWM Fans
• Triple Sickleflow 140 ARGB PWM Fan
• Triple 360mm Radiator support
• Support GPU length 485mm
• Tempered Glass side
• USB 3.2 Type-C

MasterFrame 600 Black • Triple 360mm Radiator support
• Support GPU length 485mm
• Rear Mobius 120 PWM Fans
• Triple Mobius 140 PWM Fan
• Tempered Glass side
• USB 3.2 Type-C

An Impressive Structure

Versatile and maker-driven. Its open source design and interchangeable panels offer endless personalisation possibilities, transforming your chassis into a unique expression of style.

Freeform 2.0 exo-structure. The exposed frame structure enhances chassis adaptability and provides flexible configuration options for various scenarios.

Included GPU support bracket. The included GPU support bracket prevents GPU sag and ensures stability during intense gaming or high-performance workloads, maintaining a clean and secure build.

Compatibility of the MasterFrame 600

Flexible motherboard support Supports Mini-ITX to E-ATX motherboards, offering compatibility with a wide range of builds and configurations.

Extensive cooling support The case can house up to 11 fans and multiple radiator sizes (up to 420mm), ensuring superior thermal performance.

Ample GPU clearance The MasterFrame 600 accommodates graphics cards up to 485mm, offering plenty of space for high-end GPUs.

Specifications

Core Chassis Specifications
Case Edition	MasterFrame 600 Silver
Case Form Factor	Mid Tower
Motherboard Form Factor	ATX E-ATX MicroATX Mini-DTX Mini-ITX SSI CEB
Back Connect Compatible	No

I/O, Bays & Expansion
Front/Side/Top Panel I/O	1 x Headphone/Mic Combo 1 x Power Button 2 x USB 3.2 Gen1 Type-A 1 x USB 3.2 Gen2x2 Type-C
Drive Bays	3 x 2.5" Internal 2 x 2.5"/ 3.5" Internal
Standard Expansion Slots	8
Vertical Expansion Slots

Fans & Filters
Fan Bays	10 x 120mm / 8x 140mm 4 x 180mm 3 x 200mm
Fans Included	1 x 120mm w/ Addressable RGB LEDs 3 x 140mm w/ Addressable RGB LEDs
Fan Controller/Hub	Built-in Fan Hub
Dust Filters	Bottom Front Side Top

Liquid Cooling Support
Front Radiator Compatibility	1 x 120/140/240/280/360/420mm
Top Radiator Compatibility	1 x 120/140/240/280/360/420mm
Bottom Radiator Compatibility
Rear Radiator Compatibility	1 x 120mm
Side Radiator Compatibility	1 x 240/280/360/420mm

Clearances
Max CPU Cooler Height	190 mm
Max GPU Card Length	485 mm
Cable Routing Space	43 mm

Side Panels
Window/s	No
Window Configuration	1 x Main Side
Window Construction	Tempered Glass

LED Lighting Functionality
LED Lighting	Yes
LED Lighting Emitters	Included Addressable LED Fan/s
LED Lighting Colour	RGB
LED Lighting Support & Control

Power Supply Compatibility
PSU Included	No
PSU Wattage (If Included)
PSU 80+ Rating (If Included)
PSU Support
PSU Mounting Location	Bottom Mount, Rear
Max PSU Length	235 mm

Chassis Physical Specifications
Colour	Silver
Chassis Construction Materials	SGCC / Tempered Glass
Front Panel Type	N/A
Dimensions	261 x 544 x 531 (WxHxD mm)
Weight
Package Type
Please Note

Additional Information
Scan Code	LN160552
Model Number	MF600-SGNN-S00
GTIN	4719512158302
