AMD Opteron 142 CPU Socket

Prouct details for the 1.6GHz Model 142

Integrated DDR memory controller
Yes
Memory controller width
128-bit
ECC DRAM protection
Yes
HyperTransport™ Technology
Yes
HyperTransport Links (total/coherent)
3/0
HyperTransport Link width
16 bits x 16 bits
HyperTransport bus frequency
800MHz
AMD64
Yes
Simultaneous 32 & 64-bit computing
Yes
L1 Cache Size (data/instruction)
64KB/64KB
L2 Cache Size
1MB
Pipeline stages (integer/floating point)
12-17
L1/L2 data cache protection
ECC
L1/L2 instruction cache protection
Parity
Global History Counter Entries
16K
L1 TLB entries (data/instruction)
40/40
L1 associativity (data/instruction)
Full/Full
L2 TLB entries (data/instruction)
512/512
L2 associativity (data/instruction)
4-way/4-way
Process
.13 micron SOI
Manufactured In
Fab 30, Dresden Germany

For further information regarding Scan's warranty procedure please click here

Details

Duration: 36 months

Type: Direct

DOA Period: 28 days

RTB Period: 12 months

Manufacturer Contact Details

Manufacturer: Scan / AMD Europe

Telephone: 01276 932318

Additional Notes:
"Please be aware any warranty offered in excess of 12 months is at the manufacturer's discretion and maybe subject to change without notice."

Subject to, 3 years manufacturer's warranty.

1st year warranty return to Scan Computers;
2nd - 3rd year subject to manufacturers warranty via AMD Europe
+44 (0) 1276-803187

Please be prepared to provide AMD Europe the following information:
(1) your name, address, and telephone numbers;
(2) proof of purchase;
(3) a description of the type of boxed processor;

Upon receipt of a Return Material Authorization (RMA) number from the Technical Service Center Representative, you will be required to send in your processor, and heatsink/fan that were packaged together in the retail container. The packaging materials themselves will not be required to process your RMA.

http://www.amd.com/us-en/Processors/TechnicalResources/0,,30_182_867_1034,00.html

This Warranty does not cover any damage due to abnormal use or conditions, misuse, neglect, abuse, accident, improper handling or storage, serial number altered, defaced or removed; or has had the warranty seal on the system altered, defaced or removed, exposure to moisture, unauthorized modifications, alterations, or repairs, improper installation, improper use of any electrical source, undue physical or electrical stress, operator error, non-compliance with instructions.

CPUs >> AMD 64 Processors

This TekSpek explains what AMD’s AMD64 CPU instruction set architecture (ISA) is, shows what CPUs implement it from both AMD and Intel, and explains what software is available to run on those 64-bit consumer processors.

CPUs >> Architecture wars

Intel’s Core 2 Duo is now slugging it out against AMD’s Socket AM2 Athlon 64s with DDR2 memory support. So what is next on the roadmap from the two chip-vending foes?

CPUs >> Cores

Over the course of the last year or so we’ve seen GHz become less of a focus when it comes to processors. Instead, we’re seeing a shift towards processors that do more work per clock, have larger caches, are more power efficient, and of course we’ve seen dual-core processors hit the market. So what is dual-core all about, and how does it weigh up compared to single-core?

CPUs >> CPU Codes

It’s been a long time since MHz were the only part of a CPU’s specification that concerned people. Manufacturers take different approaches to CPU design, even when using the same architecture. That means for example, at the same clock speed, an Intel and AMD processor will deliver different performance.

Motherboards >> Chipsets

What makes a PC tick? Is it the processor, graphics card, RAM, or a plethora of other peripherals. It’s all those and more, but none would be much use without a means of connecting said components in an efficient manner. That’s where your humble motherboard comes in. Its job is to ensure that all devices can communicate correctly, and the beating heart of any motherboard is the chipset it’s based upon.

Motherboards >> How to upgrade your BIOS

This How-2 Guide explains what BIOS is and how it can be upgraded to the latest revision. BIOS, which stands for Basic Input/Output System, is a integral software program that comes pre-loaded with your computer. Its purpose is to initially identify computer hardware and prepare the system to run other software such as operating systems.

Manufacturer:	AMD	Graphics Clock:	N/A
CPU Type:	Opteron 64	FSB/HT Speed:	1600MHz
CPU Model:		Max. Memory Speed:
Socket:	940	L1 Cache (Total):	128KB
CPU Features:		L2 Cache (Total):	1MB
Core:		L3 Cache (Total):
Core Name:		Voltage:	1.65 (V)
Core Size:	130 nm	Wattage:
Clock Speed:	1.6 GHz	Max. Temperature:
Turbo Speed:	N/A	EM64T:
Graphics Chipset:		Heatsink:
Graphics Cores:	N/A	Package Type:

	CPU Type:	Opteron 64
	CPU Model:
	Socket:	940
	CPU Features:
	Core:
	Core Name:
	Core Size:	130 nm
	Clock Speed:	1.6 GHz
	Turbo Speed:	N/A
	Graphics Chipset:
	Graphics Cores:	N/A
	Graphics Clock:	N/A
	FSB/HT Speed:	1600MHz
	Max. Memory Speed:
	L1 Cache (Total):	128KB
	L2 Cache (Total):	1MB
	L3 Cache (Total):
	Voltage:	1.65 (V)
	Wattage:
	Max. Temperature:
	EM64T:
	Heatsink:
	Package Type:

Show me:

Total (inc VAT)

£0.00

Order now to receive by Monday 28^th May 2012

OSA142BOX - AMD Retail 1-Way Opteron 142 (1600MHz) 64Bit CPU (S940) 1024L2 Cache with AMD Heat Sink Fan 3Yr
