USE LN 46798 - Hynix 4GB DDR3 PC3-10600 (1333) Single Channel Server Memory
End Of Life
USE LN 46798 - Hynix 4GB DDR3 PC3-10600 (1333) Single Channel Server Memory
Scan code: LN27484 Manufacturer code: HMT151R7TFR4C-H9D2-C
End Of Life
USE LN 46798 - Hynix 4GB DDR3 PC3-10600 (1333) Single Channel Server Memory : image 1
  • Thumbnail 1 : USE LN 46798 - Hynix 4GB DDR3 PC3-10600 (1333) Single Channel Server Memory
End Of Life

USE LN 46798 - Hynix 4GB DDR3 PC3-10600 (1333) Single Channel Server Memory

USE LN 46798 - 4GB Hynix Server Memory, DDR3, PC3-10600 (1333MHz), 240 Pin, Registered, CAS 9-9-9
MORE INFO
MORE INFO

Scan code: LN27484 Manufacturer code: HMT151R7TFR4C-H9D2-C
End of life
This product is no longer available to purchase.

Email me when the availability or price changes

  • SCANPROTECT Protect against installation damage for 28 days.
Product Overview This Hynix DDR3 SDRAM Registered Dual In-Line Memory Module (DIMM) series consists of 1Gb A generation. These are intended for use as main memory in server and workstation systems, providing a high performance 8 byte interface in 133.35mm width form factor of industry standard. It is suitable for easy interchange and addition. Features • Fully differential clock inputs (CK, CK) operation
• Differential Data Strobe (DQS, DQS)
• On chip DLL align DQ, DQS and /DQS transition with CK transition
• DM masks write data-in at the both rising and falling edges of the data strobe
• All addresses and control inputs except data, data strobes and data masks latched on the rising edges of the clock
• Programmable burst length 4/8 with both nibble sequential and interleave mode
• BL switch on the fly
• 8K refresh cycles /64ms
• Driver strength selected by EMRS
• Dynamic On Die Termination supported
• Asynchronous RESET pin supported
• ZQ calibration supported
• TDQS (Termination Data Strobe) supported (x8 device based only)
• Write Levelization supported
• Auto Self Refresh supported
• 8 bit pre-fetch
• SPD with Integrated TS of Class B
Warranty

Please note your statutory rights are not affected.

For further information regarding Scan's warranty procedure please see our terms and conditions

Details
Duration:
24 months
Type:
Return to base
DOA Period:
7 days
RTB Period:
24 months
Manufacturer Contact Details
Manufacturer:
Scan

Additional Notes:
Lifetime Manufacturer Warranty Direct
